Product

Architecture

ARM 9,Linux,64Mbyte   RAM, 256Mbyte flash

Operating Frequency

860MHz-868Mhz,CE,902-   920MHz,   frequency band adjustable

Operation   Mode

FHSS   or fixed frequency

Power   output

+20dBm   ~ +30dBm@50Ω load, 1dBm each step

Antenna

Built-in   12dBi linear antenna (horizontal/vertical customized)

Communication   Interfaces

RS-232,   Weigand 26/34; Ethernet, RS485 optional

Wireless   Function

4G, WIFI 802.11module

I/O   Interfaces

2-channel   Relay Output, 2-channel Trigger Input

Firmware   Upgrade

Support   serial port and Ethernet

Application   Software Platform

API(C++,   C#) development kit (can be customized)

Tag Operation

Tag Protocol

EPC Class1 Gen2 (ISO18000-6C)

Reading Range

0~15m

 Writing   Range

0~5m

Mechanical& Electrical performance

Dimensions

445mm   x445mm x 78mm (LxWxH)

Package   Dimensions

600mm   x500mm x 110mm

Weight

3.47kg

Power   Supply

DC12V input, PoE   optional

Operating   Temperature

 -40°C~+60°C

Humidity

5%~95%(non-condensing)

Waterproof

IP65
